Intel Core i5-14400F

Product Collection

13th Generation Intel® Core™ i5 Processors

Code Name

Products formerly Raptor Lake

Vertical Segment Desktop

Processor Number i5-13400

Lithography Intel 7

Use Conditions PC/Client/Tablet

CPU Specifications

Total Cores 10

# of Performance-cores 6

# of Efficient-cores 4

Total Threads 16

Max Turbo Frequency 4.60 GHz

Performance-core Max Turbo Frequency 4.60 GHz

Efficient-core Max Turbo Frequency 3.30 GHz

Performance-core Base Frequency 2.50 GHz

Efficient-core Base Frequency 1.80 GHz

Cache 20 MB Intel® Smart Cache

Total L2 Cache 9.5 MB

Processor Base Power 65 W

Maximum Turbo Power 154 W

Supplemental Information

Marketing Status Launched

Launch Date Q1'23

Embedded Options Available Yes

Memory Specifications

Max Memory Size (dependent on memory type) 128 GB

Memory Types Up to DDR5 4800 MT/s

Up to DDR4 3200 MT/s

Max # of Memory Channels 2

Max Memory Bandwidth 76.8 GB/s

Processor Graphics

Processor Graphics Intel® UHD Graphics 730

Graphics Base Frequency 300 MHz

Graphics Max Dynamic Frequency 1.55 GHz

Graphics Output eDP 1.4b, DP 1.4a, HDMI 2.1

Execution Units 24

Max Resolution (HDMI) 4096 x 2160 @ 60Hz

Max Resolution (DP) 7680 x 4320 @ 60Hz

Max Resolution (eDP - Integrated Flat Panel) 5120 x 3200 @ 120Hz

DirectX* Support 12

OpenGL* Support 4.5

OpenCL* Support 3.0

Multi-Format Codec Engines 1

Intel® Quick Sync Video Yes

Intel® Clear Video HD Technology Yes

of Displays Supported 4

Device ID 0x4682/0xA782

Expansion Options

Direct Media Interface (DMI) Revision 4.0

Max # of DMI Lanes 8

Scalability 1S Only

PCI Express Revision 5.0 and 4.0

PCI Express Configurations Up to 1x16+4, 2x8+4

Max # of PCI Express Lanes 20

Package Specifications

Sockets Supported FCLGA1700

Max CPU Configuration 1

Thermal Solution Specification PCG 2020C

TJUNCTION 100°C

Package Size 45.0 mm x 37.5 mm

Advanced Technologies

Intel® Gaussian & Neural Accelerator 3.0

Intel® Thread Director Yes

Intel® Deep Learning Boost (Intel® DL Boost) Yes

Intel® Speed Shift Technology Yes

Intel® Turbo Boost Max Technology 3.0 No

Intel® Turbo Boost Technology 2.0

Intel® Hyper-Threading Technology Yes

Intel® 64 Yes

Instruction Set 64-bit

Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2

Idle States Yes

Enhanced Intel SpeedStep® Technology Yes

Thermal Monitoring Technologies Yes

Intel® Volume Management Device (VMD) Yes

Security & Reliability

Intel® Standard Manageability (ISM) Yes

Intel® Control-Flow Enforcement Technology Yes

Intel® AES New Instructions Yes

Secure Key Yes

Intel® OS Guard Yes

Execute Disable Bit Yes

Intel® Boot Guard Yes

Mode-based Execute Control(MBEC) Yes

Intel® Virtualization Technology (VT-x) Yes

Intel® Virtualization Technology for Directed I/O (VT-d) Yes

Intel® VT-x with Extended Page Tables (EPT) Yes
